High frequency welded condenser tube

Nanjing Majestic established in 2007 and located in Nanjing, Jiangsu Province, China. We are one of the largest manufacturers of aluminum tubes in China, We design and manufacture all kinds of aluminum tubes,such as high frequency welded radiator tube, high frequency welded intercooler tube,high frequency welded condenser tube,extruded aluminum tube ect. We have kinds of catalog for you to check,also can custom tubes with your drawing. If any needs, welcome to contact us.

Send Inquiry

Product Description

1.Product Introduction

The manufacturing method of the high frequency welded condenser tube is to make the aluminum strip into a flat strip, and then connect the edges through a high frequency welding process.The main difference between extruded condenser tube and high frequency welded condenser tube is that it can use multi-layer materials of different aluminum alloys. The cladding is widely used in tubes produced by heat exchangers to achieve furnace welding or flame brazing and to provide sacrificial corrosion resistance.We can provide short or long tubes, perfect round or D-shaped, ordinary tubes or ready-to-use tubes, including grooves, drill holes, baffles and welded connection blocks



2.Product Parameter (Specification)

 High frequency welded condenser tube:Round Tube (OD*wall thickness)

8*1.0/8*1.4

28*1.5/1.6

9.52*1.0/1.5

29*2.0

10*1.0/1.1

10*1.0/1.1

12*1.0/1.5

30.2*1.2

12.7*1.5

31.6*1.5

13*1.2

32*1.5/1.8/2.0/2.5

16*1.0/1.05/1.1/1.15/1.2/1.25/1.8

33.3*1.5

17*1.3

33.4*1.5

18*1.2

35*1.5/1.8

19*1.3

36*1.5

20*1.0/1.1/1.15/1.2/1.3/1.5/2.0/2.05

38*2.0

20.15*1.15

38*2.2/2.5

21*2.0

40*1.5/1.8/2.0

22*1.27/1.3/1.5

42*2.0

23*1.7

45*2.85

24*1.5

50*2.5

25*1.5/1.8

50*2.6/3.0

26*1.9/2.2

61*3.0

27*1.5/1.6



Other sizes can be customized with 10 working days.


3.Product Feature And Application

Automotive applications: Mobile air conditioner condenser
HVAC applications:Fixed condenser

4.FAQ
Q: OEM/ODM available?
A: Yes,we can!
Q: Could you provide sample?
A: Yes, We are honored to offer you samples for quality check
Q: What is your sample policy?
A: We can supply the sample if we have ready parts in stock, and you just need to pay the shipping cost.
