Aluminum Rod Tube

Nanjing Majestic is a professional industrial aluminum extrusion factory producing all series of aluminum alloy products ,such as: aluminum rod tube,aluminum rod tube and bars, aluminum tubes, aluminum profiles which are widely used in auto parts, bicycle accessories, sports equipments, furniture fittings, electronic components, machinery hardware and so on.We have more than 14 years of industry experience in the field of aluminum profiles. It has top technical talents, high-end sales team, and good pre-sales and after-sales services. Looking forward to working with you.

Send Inquiry

Product Description

1.Product Introduction
According to the different metal elements contained in aluminum rod tube, aluminum rod tube can be roughly divided into 8 categories, that is, they can be divided into 9 series:
1. The 1000 series aluminum rod tube represent the 1050, 1060, and 1100 series. In all series, the 1000 series belongs to the series with the most aluminum content. The purity can reach more than 99.00%. Because it does not contain other technical elements, the production process is relatively simple and the price is relatively cheap. It is currently the most commonly used series in conventional industries. Most of the products circulating in the market are 1050 and 1060 series. The 1000 series aluminum rod tube determine the minimum aluminum content of this series according to the last two Arabic numerals. For example, the last two Arabic numerals of the 1050 series are 50. According to the international brand naming principle, the aluminum content must reach 99.5% or more to be a qualified product. my country's aluminum alloy technical standard (gB/T3880-2006) also clearly stipulates that the aluminum content of 1050 reaches 99.5%. Similarly, the aluminum content of 1060 series aluminum rod tube must reach 99.6% or more.
2. 2000 series aluminum rod tube represent 2A16 (LY16) and 2A02 (LY6). The 2000 series aluminum rod tube are characterized by high hardness, with the highest content of copper, which is about 3-5%. The 2000 series aluminum rod tube belong to aviation aluminum materials, which are not often used in conventional industries.
2024 is a typical hard aluminum alloy in the aluminum-copper-magnesium series. It is a heat-treatable alloy with high strength, easy processing, easy turning, and general corrosion resistance.
After 2024 aluminum rod tube are heat treated (T3, T4, T351), the mechanical properties are significantly improved. Its T3 state parameters are as follows: tensile strength 470MPa, 0.2% yield strength 325MPa, elongation: 10%, fatigue strength 105MPa, hardness 120HB.
The main uses of 2024 aluminum rod tube: aircraft structure, rivets, truck wheel hubs, propeller components and other various structural parts
3. 3000 series aluminum rod tube mainly represent 3003 and 3A21. The production technology of 3000 series aluminum rod tube in my country is relatively excellent. 3000 series aluminum rod tube are made of manganese as the main component. The content is between 1.0-1.5, which is a series with better anti-rust function.
4. 4000 series aluminum rod tube The representative is 4A01 4000 series aluminum rod tube belong to the series with higher silicon content. Usually the silicon content is between 4.5-6.0%. It belongs to construction materials, mechanical parts, forging materials, welding materials; low melting point, good corrosion resistance, product description: heat-resistant and wear-resistant
5. The 5000 series aluminum rod tube represent the 5052, 5005, 5083, and 5A05 series. The 5000 series aluminum rod tube belong to the more commonly used alloy aluminum rod series, the main element is magnesium, and the magnesium content is between 3-5%. It can also be called aluminum-magnesium alloy. The main features are low density, high tensile strength and high elongation. In the same area, the weight of aluminum-magnesium alloy is lower than that of other series, and it is also widely used in conventional industries. In my country, the 5000 series aluminum rod is one of the more mature aluminum rod series.
6. 6000 series aluminum rod tube represent 6061 and 6063 mainly containing magnesium and silicon. Therefore, the advantages of 4000 series and 5000 series are concentrated. 6061 is a cold-treated aluminum forging product, suitable for applications with high requirements for corrosion resistance and oxidation. . Good workability, easy coating, and good processability.
7. 7000 series aluminum rod tube represent 7075 and mainly contain zinc. It also belongs to the aerospace series. It is an aluminum-magnesium-zinc-copper alloy, a heat-treatable alloy, and a super-hard aluminum alloy with good wear resistance. Basically relying on imports, my country's production technology needs to be improved.
8. 8000 series aluminum rod tube The more commonly used 8011 belongs to other series, and most of the applications are aluminum foil, which is not commonly used in the production of aluminum rod tube.

2.Product Parameter (Specification)

Product Name

Aluminum Rod Tube


1050 1060 1100 2014 3003 5052 6061,6063 7075 etc


O-H112 T3-T8

Surface treatment

Mill Finish,Anodized,Eletropharesis,Powder Coated, Paiting,Polish,Sandblasting,brushed




Round,Square,Rectangle,Triangle,Hexagon,Octagon,Oval,or as per the drawings and samples

Deep Process

cutting,drilling,punching,milling,deburring,clearing,tapping etc

Wall thickness

> 0.3mm

Section size

Square: ≤ 150*150mm

Rectangle:≤ 250*50mm

Round: ≤ ∅170mm


inner plastic paper interleaving each tube,outer fixed by plywood or pallets,or as required

Delivery time

15-25 days after deposit


ISO9001,IATF(ISO/TS)16949, ISO14001

Q:Can you produce according to the samples?
A:Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.
Q:How to ship?
A:Sea freight,Air freight,express;
Q:What is your terms of delivery?
A:We can do EXW, FOB,FCA, CFR, CIF.ect
